480 Achilles Load Data













  • All loads use CCI Large Pistol Primers
  • All loads with the Bittner 480-290-FNH bullet  (290 gr. heel bullet)
  • All fired from 7 barrel
  • 7 feet from muzzle to first screen
  • All velocities are averages

Black Powder

21.0 gr. FFg DuPont - 643 fps (these were VERY consistent)

WW 231

6.0 gr. 231 = 794 fps


Bullseye

5.0 gr. Bullseye = 717 fps
6.0 gr. Bullseye = 883 fps

700X

6.0 gr. 700X = 906 fps

Unique

6.1 gr. Unique = 798 fps
6.5 gr. Unique = 848 fps
7.0 gr. Unique = 911 fps

2400

12.0 gr. 2400 = 870 fps (accurate load)
12.5 gr. 2400 = 885 fps
13.0 gr. 2400 = 950 fps (accurate load)


WC820 (military surplus H110)

15.5 gr. WC820 = 883 fps
16.0 gr. WC820 = 955 fps


Targets


Some representative
targets fired with
various loads

All at 25 yards
